AFL2-12A-HM65 Series Panel PC
Page 16
1.1 AFL2-12A-HM65 Flat Bezel Panel PC Overview
Figure 1-1: AFL2-12A-HM65 Flat Bezel Panel PC
The AFL2-12A-HM65 is an Intel® Sandy Bridge Mobile CPU powered flat bezel panel PC
with a rich variety of functions and peripherals. The AFL2-12A-HM65 is designed for easy
and simplified integration into kiosk and point-of-sales (POS) applications.
An Intel® Sandy Bridge Mobile CPU coupled with an Intel® HM65 input/output controller
hub ensures optimal memory, graphics, and peripheral I/O support. The system comes
with 1.0 GB of preinstalled DDR3 SDRAM ensuring smooth data throughputs with reduced
bottlenecks and fast system access.
Three serial ports, two external USB 2.0 ports and two external USB 3.0 ports ensure
simplified connectivity to a variety of external peripheral devices. Wi-Fi capabilities and
dual RJ-45 Ethernet connector provide the system with smooth connection to an external
LAN. An optional MSR card reader can equip the system for scanning credit cards,
identification cards, loyalty cards, gift cards, and more.
1.1.1 Model Variations
The model variations of the AFL2-12A-HM65 Series are listed below.
