IEI Integration AFL2-12A-HM65 v1.00 - Manual (Page 17)

AFL2-12A-HM65 Series Panel PC
Page 17
Model No. Touch Screen Type Optional Features
AFL2-12A-HM65/PC-EM-R10 Projective capacitive EM card reader
AFL2-12A-HM65/PC-MF-R10 Projective capacitive MIFARE card reader
AFL2-12A-HM65/PC-R10 Projective capacitive N/A
AFL2-12A-HM65/R-EM-R10 5-Wire Resistive EM card reader
AFL2-12A-HM65/R-MF-R10 5-Wire Resistive MIFARE card reader
AFL2-12A-HM65/R-R10 5-Wire Resistive N/A
Table 1-1: AFL2-12A-HM65 Model Variations
1.1.2 Features
The AFL2-12A-HM65 features are listed below:
 12.1” 600 cd/m 2
XGA LCD
 Intel® Sandy Bridge Mobile CPU supported
 Intel® HM65 chipset
 1.0 GB 800 MHz DDR3 SO-DIMM preinstalled (4 GB maximum)
 RFID module compatible with EM or MIFARE cards
 Watchdog timer that triggers a system reset if the system hangs for some
reason
 IP 64 compliant front panel
 AT or ATX power mode
 5-Wire Resistive or Projected Capacitive type touch screen
 RoHS compliance
 Auto-dimming control
 1.3 megapixel webcam
1.1.3 Applications
AFL2-12A-HM65 Series panel PCs are elegant, sophisticated systems that can be easily
implemented in commercial, industrial and corporate environments.
