AFL2-12A-HM65 Series Panel PC
Page 25
Brightness (cd/m 2 ) 600
Contrast Ratio 700:1
LCD Color 16.2M
Pixel Pitch (H x V) (mm) 0.240 (H) x 0.240 (V)
Viewing Angle (H-V) 176 / 176
Backlight MTBF (hr) 50,000
Touch Screen 5-Wire resistive type touchscreen (select models only)
Projected capacitive type touchscreen (select models only)
SBC Model AFL2MB2-PV-HM65
CPU Intel® Sandy Bridge Mobile CPU
Chipset Intel®HM65
Ethernet Realtek RTL8111E PCIe GbE controller supports ASF2.0
Memory One 204-pin DDR3 SO-DIMM slot pre-installed (4 GB system max.)
Expansion Mini PCIe slot for WiFi
One PCIe x1 slot for LAN card expansion
Drive Bay One 2.5” SATA 3.0 HDD bay
SSD SATA SSD
One PCIe mini slot with SATA signal and IEI MiniDOM support
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio AMP 1.5 W + 1.5 W (built-in stereo speakers)
Wi-Fi Wi-Fi module 802.11 b/g/n
RFID EM or MIFARE card reader
MSR Module MSR card reader (Optional)
Construction Material ABS + PC plastic front frame
Mounting Wall
Rack
Stand
Arm (VESA 100 mm x 100 mm)
Front Panel Color Black
Net Weight 3.8 kg / 6.1 kg
Dimensions (W x H x D) (mm) 310 x 265 x 52.6
Operation Temperature -20ºC ~ 50ºC
Storage Temperature -20ºC ~ 60ºC
IP level IP 64 compliant front panel
