AFL2-12A-HM65 Series Panel PC

Page 161

C.4 Setup Procedure for Linux

The initial setup procedure for Linux system is mostly the same with the procedure for

Microsoft Windows. Please follow the steps below to setup recovery tool for Linux OS.

Step 1:

Hardware and BIOS setup. Refer to Section C.2.1.

Step 2:

Install Linux operating system. Make sure to install GRUB (v0.97 or earlier)

MBR type and Ext3 partition type. Leave enough space on the hard drive to

create the recover partition later.

NOTE:

If the Linux OS is not installed with GRUB (v0.97 or earlier) and Ext3,

the Symantec Ghost may not function properly.

While installing Linux OS, please create two partitions:

 Partition

SWAP

NOTE:

Please reserve enough space for partition 3 for saving recovery

images.

Figure C-29: Partitions for Linux
