AFL2-12A-HM65 Series Panel PC

Page 20

LED Indicator

Description

Audio Mute

Lights on when the audio is turned off. Controlled by the

hot keys. See Table 1-3

Function

LCD On/Off

Audio Volume Down

Audio Volume Up

Brightness Down

Brightness Up

Shows the status of the function key below the LED

indicator. Blinks when the corresponding button is pushed.

Table 1-2: LED Indicators

NOTE:

If the CPU temperature alert LED shows in red, the user must lower the

environments temperature or close some running applications to cool

down the CPU.

The corresponding Function Keys are located under the bottom right hand corner of the

LCD screen (Figure 1-4).

Figure 1-4: Function Keys
