5.4.2.2 NB P CIe Co n fig u ra tio n
Use the NB PCIe Configuration submenu (BIOS Menu 22) to configure the northbridge
PCIe settings.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0
x0 Gen1
PEG0-Gen X [Gen1]
Enable PEG [Enabled]
Detect Non-Compliance Device [Enabled]
Configure PEG0 B0:D1:F0
Gen1-Gen3 (PCIEX16_1
Slot)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 22: NB PCIe Configuration
 PEG0-Gen X [Gen 1]
Use the PEG0-Gen X option to configure PEG0 B0:D1:F0. Configuration options are listed
below.
 Auto
 Gen1 Default
 Gen2
 Gen3
 En ab le P EG [En ab led ]
Use the Enable PEG option to enable or disable PEG.

Disabled Disables PEG.

Enabled D EFAULT Enables PEG.

Auto Automatically detect PEG
