TANK-6000-C226 Em b e d d e d S ys te m
P a g e 57
5.3.9 iWDD H/W Mo n ito r
The iWDD H/W Monitor menu (BIOS Menu 12) contains the fan configuration submenus
and displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU Temperature :+49 C
SYS Temperature :+27 C
CPU_FAN1 Speed :709 RPM
SYS_FAN1 Speed :N/A
CPU_CORE :+1.743 V
+5V :+5.126 V
+12V :+12.175 V
DDR :+1.502 V
+5VSB :+4.896 V
+3.3V :+3.357 V
+3.3VSB :+3.276 V
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 12: iWDD H/W Monitor
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speeds:
o CPU Fan Speed
o System Fan Speed
 Voltages:
o CPU_CORE
o +5V
o +12V
o DDR
o +5VSB
