TANK-6000-C226 Em b e d d e d S ys te m
P a g e 35
Co n n e c to r
Typ e
La b e l
USB 2.0 connector
Dual USB 2.0 port
USB_CON3
VGA connector
15-pin female
VGA1
Table 4-13: Rear Panel Connectors
4.3.1 Au d io In p u t & Ou tp u t Co n n e c to rs (MIC1, AUDIO1)
PIN NO.
DESCRIPTION
MIC1 (Line_Out)
Connect this port to headphone or speaker
AUDIO1 (Microphone)
Connect this port to microphone
Table 4-14: Audio Input & Output Connectors (MIC1, AUDIO1) Pinouts
4.3.2 DC-in P o we r Co n n e c to r (U56)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
Vin
2
Vin
3
GND
4
GND
Table 4-15: DC-in Power Connector (U56) Pinouts
4.3.3 Eth e rn e t Co n n e c to rs (LAN1_2)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
A1
LAN1_MDI0P
B1
LAN2_MDI0P
A2
LAN1_MDI0N
B2
LAN2_MDI0N
A3
LAN1_MDI1P
B3
LAN2_MDI1P
A4
LAN1_MDI1N
B4
LAN2_MDI1N
A5
LAN1_MDI2P
B5
LAN2_MDI2P
A6
LAN1_MDI2N
B6
LAN2_MDI2N
A7
LAN1_MDI3P
B7
LAN2_MDI3P
A8
LAN1_MDI3N
B8
LAN2_MDI3N
Table 4-16: Ethernet Connector (LAN1_2) Pinouts
