TANK-6000-C226 Em b e d d e d S ys te m
P a g e 38
1 VCC 10 VCC
2 USB_DATA- 11 USB_DATA-
3 USB_DATA+ 12 USB_ DATA+
4 GND 13 GND
5 USB3_RX- 14 USB3_RX-
6 USB3_RX+ 15 USB3_ RX+
7 GND 16 GND
8 USB3_TX- 17 USB3_TX-
9 USB3_TX+ 18 USB3_TX+
Table 4-22: USB 3.0 Connector (USB_CON4) Pinouts
4.3.10 US B 2.0 Co n n e c to rs (US B_CON3)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC 5 VCC
2 USB_DATA- 6 USB_DATA-
3 USB_DATA+ 7 USB_DATA+
4 GND 8 GND
Table 4-23: USB 3.0 Connector (USB_CON3) Pinouts
4.3.11 VGA Co n n e c to r (VGA1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 RED 2 GREEN
3 BLUE 4 NC
5 GND 6 GND
7 GND 8 GND
9 VCC 10 GND
11 NC 12 DDCDA
13 HSYNC 14 VSYNC
15 DDCCLK
Table 4-24: VGA Connector (VGA1) Pinouts
