TANK-6000-C226 Em b e d d e d S ys te m
P a g e 32
4.2.5 Fa n Co n n e c to rs (CP U_FAN1, S YS _FAN2)
4.2.6 Fla s h BIOS ROM Co n n e c to r (J S P I1)
4.2.7 Fla s h EC ROM Co n n e c to r (J S P I2)
PIN NO. DESCRIPTION
1 GND
2 +12V
3 FANIO
4 PWM
Table 4-6: Fan Connectors (CPU_FAN1, SYS_FAN2) Pinouts
PIN NO. DESCRIPTION
1 +V3.3M_SPI_CON
2 SPI_CS#0_CN
3 SPI_SO_SW
3 SPI_CLK_SW
5 SPI_SI_SW
6 GND
Table 4-7: Flash BIOS ROM Connector (JSPI1) Pinouts
PIN NO. DESCRIPTION
1 +3.3V
2 SPI_CS#
3 SPI_SO
3 NC
5 GND
6 SPI_CLK
7 SPI_SI
8 NC
Table 4-8: Flash EC ROM Connector (JSPI2) Pinouts
