TANK-6000-C226 Em b e d d e d S ys te m
P a g e 17
Figure 3-6: Installing the HDD
S te p 4: Install the HDD bracket in the same position it was before and tighten the HDD
bracket retention screws.
S te p 5: Lock the HDD drive bay using the key
3.4 P CIe Expa n s io n Ca rd In s ta lla tio n (Op tio n a l)
To install a PCIe expansion card, please do the following.
S te p 1: Loosen the two thumbscrews on the rear panel and remove the top cover. Then
remove the two retention screws and open the side cover.
Figure 3-7: Unscrew the cover
