5.4.1 P CH-IO Co n fig u ra tio n
Use the PCH-IO Configuration menu (BIOS Menu 17) to configure the PCH chipset.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled (ATX)]
Restore AC Power Loss [Last State]
> PCH Azalia Configuration
Power Saving Function(ERP) [Disabled]
USB Power SW1
[+5V DUAL]
Select AC power state
when power is re-applied
after a power failure.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 17: PCH-IO Configuration
 Res to re o n AC Po wer Lo s s [Las t State ]
Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.

Power Off The system remains turned off

Power On The system turns on

Last State D EFAULT The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
 Po wer Savin g Fu n ctio n [Dis ab led ]
Use the Power Saving Function BIOS option to enable or reduce power consumption in
the S5 state. When enabled, the system can only be powered-up using the power button.

Disabled D EFAULT Power Saving Function support disabled
