5.3.8.1 S e ria l P o rt n Co n fig u ra tio n
Use the Serial Port n Configuration menu (BIOS Menu 11) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=3F8h;IRQ=4
Change Settings
[Auto]
Enable or Disable Serial
Port (COM)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
= - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 11: Serial Port n Configuration Menu
5.3.8.1.1 S e ria l P o rt 1 Co n fig u ra tio n
 Serial Po rt [En ab led ]
Use the Serial Port option to enable or disable the serial port.

Disabled Disable the serial port

Enabled D EFAULT Enable the serial port
 Ch an g e S ettin g s [Au to ]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.

IO=3F8h;
IRQ=4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ4
