TANK-6000-C226 Em b e d d e d S ys te m
P a g e 46
 ACP I Sle ep State [S 1 o n ly (CPU Sto p Clo ck)]
Use the ACPI Sleep State option to specify the sleep state the system enters when it is
not being used.

S1 only (CPU Stop
Clock)
D EFAULT The system enters S1 (POS) sleep state. The
system appears off. The CPU is stopped; RAM is
refreshed; the system is running in a low power
mode.

S3 only (Suspend
to RAM)
The caches are flushed and the CPU is powered
off. Power to the RAM is maintained. The
computer returns slower to a working state, but
more power is saved.
5.3.2 RTC Wa ke S e ttin g s
The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event. The RTC
wake function is supported in ACPI (S3/S4/S5) and APM soft off modes.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Wake System with Fixed Time
[Disabled]
Enables or Disables
system wake on alarm
event. When enabled,
system will wake on the
date: hr: min: sec
specified.
----------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 4: RTC Wake Settings
