TANK-6000-C226 Em b e d d e d S ys te m
P a g e 3
1.3 Fe a tu re s
The TANK-6000-C226 features are listed below:
 LGA1155 socket supports Intel® Xeon® E3 / Core™ i3 CPU (up to 95W
CPU )
 4 x 240-pin DDR3 U-DIMM (system max: 64GB)
 Extended temperature design supports -20°C to 55°C
 Easy to install Hard Disk Drive (HDD)
 USB 3.0 for high super speed data transfer
 Programmable OLED display
 RoHS compliant
1.4 Te c h n ic a l S p e c ific a tio n s
The TANK-6000-C226 technical specifications are listed in
331H
Table 1-2.
Ch a s s is
Co lo r Black
Dim e n s io n s (WxHxD) 310 mm x 199.5 mm x 112 mm
S ys te m Fa n 92 x 92 mm Fan
Ch a s s is Co n s tru c tio n Extruded aluminum alloy
Heavy duty steel sheet
Mo th e rb o a rd
CP U LGA1155 socket supports Intel® Xeon® E3 / Core™ i3 CPU (up to
95W CPU )
Ch ip s e t Intel® C226
Me m o ry 4 x 240-pin DDR3 U-DIMM (system max: 64GB)
S to ra g e
S ATA 3 x 2.5'' HDD/SSD storage
(1 x SATA 3Gb/s, 2 x SATA 6Gb/s)
