TANK-6000-C226 Em b e d d e d S ys te m
P a g e 2
1.1 Ove rvie w
Figure 1-1: TANK-6000-C226
The TANK-6000-C226 embedded system is with one VGA port and one HDMI port for
dual display. It accepts an Intel® Xeon® E3 / Core™ i3 CPU and supports four 240-pin
DDR3 U-DIMM modules up to 64 GB. The TANK-6000-C226 supports one 2.5” SATA
HDD with up to 3 Gb/s data transfer rate and two 2.5” SATA HDDs with up to 6 Gb/s data
transfer rate. Two serial ports, two external USB 2.0 ports and four external USB 3.0 ports
ensure simplified connectivity to a variety of external peripheral devices.
1.2 Mo d e l Va ria tio n s
The model variations of the TANK-6000-C226 series are listed below.
Models CPU
TANK-6000-C226i-E3/4G-R10 Intel® quad-core Xeon® E3-1225 v3 3.2GHz (TDP 84W)
TANK-6000-C226i-i3/4G-R10 Intel® dual-core Core™ i3- 4330 3.5GHz (TDP 54W)
Table 1-1: Model Variations
