5.3.9.1 S m a rt Fa n Mo d e Co n fig u ra tio n
Use the Smart Fan Mode Configuration submenu (BIOS Menu 13) to configure smart
fan temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control [Auto Mode]
Fan start temperature 50
Fan off temperature 40
Fan start PWM 30
Fan slope PWM 1
SYS_FAN1 Smart Fan Control [Auto Mode]
Fan start temperature 50
Fan off temperature 40
Fan start PWM 30
Fan slope PWM 1
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 13: Smart Fan Mode Configuration
 CPU_FAN1 Sm a rt Fan Co n tro l/SYS_FAN1 Sm art Fa n Co n tro l [Au to Mo d e ]
Use the CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control option to
configure the CPU/System Smart Fan.

Auto Mode D EFAULT The fan adjusts its speed using Auto Mode
settings.

Manual Mode The fan spins at the speed set in Manual Mode
settings.
 Fan s tart/o ff tem p eratu re
Use the + or – key to change the Fan start/off temperature value. Enter a decimal
number between 1 and 100.
