ECW-281B/281B2-R30/N270 Embedded System
Page 78
BIOS SETUP UTILITY
Advanced
ACPI Settings
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Suspend mode [S1 (POS)]
Select the ACPI state
used for System Suspend.
Select Screen
↑ ↓ Select
Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 9: ACPI Configuration
Suspend mode [S1 (POS)]
Use the Suspend mode BIOS option to specify the sleep state the system enters when it
is not being used.
S1 (POS) D EFAULT
System appears off. The CPU is stopped; RAM is
refreshed; the system is running in a low power mode.
S3 (STR) System appears off. The CPU has no power; RAM is in
slow refresh; the power supply is in a reduced power
mode.
5.3.5.2 APM Configuration
The APM Configuration menu (BIOS Menu 10) allows the advanced power
management options to be configured.
