ECW-281B/281B2-R30/N270 Embedded System
Page 149
Partition 1: /
Partition 2: SWAP
NOTE:
Please reserve enough space for partition 3 for saving recovery
images.
Figure B-30: Partitions for Linux
Step 3: Create a recovery partition . Insert the recovery CD into the optical disk drive.
Follow Step 1 ~ Step 3 described in Section B.2.2. Then type the following
commands (marked in red) to create a partition for recovery images.
system32> diskpart
DISKPART> list vol
DISKPART> sel disk 0
DISKPART> create part pri size= ___
DISKPART> assign letter=N
DISKPART> exit
system32> format N: /fs:ntfs /q /v:Recovery /y
system32> exit
Step 4: Build the recovery partition . Press any key to boot from the recovery CD. It will
take a while to launch the recovery tool. Please be patient. When the recovery
tool setup menu appears, type <3> and press (Figure B-31). The
Symantec Ghost window appears and starts configuring the system to build a
