5.3.1 CPU Configuration

Use the CPU Configuration menu (BIOS Menu 3) to view detailed CPU specifications

and configure the CPU.

BIOS SETUP UTILITY

Advanced

Configure advanced CPU Settings
Module Version:3F.10

⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯

Manufacturer :Intel
Genuine Intel(R) CPU N270 @ 1.60GHz
Frequency :1.60GHz
FSB Speed :532Hz

Cache L1 :24 KB
Cache L2 :512 KB

Ratio Actual Value:12








Select

Screen

↑ ↓ Select

Item

F1 General

Help

F10

Save and Exit

ESC Exit

v02.61 ©Copyright 1985-2006, American Megatrends, Inc.

BIOS Menu 3: CPU Configuration

The CPU Configuration menu (BIOS Menu 3) lists the following CPU details:

Manufacturer: Lists the name of the CPU manufacturer

Brand String: Lists the brand name of the CPU being used

Frequency: Lists the CPU processing speed

FSB Speed: Lists the FSB speed

Cache L1: Lists the CPU L1 cache size

Cache L2: Lists the CPU L2 cache size

Ratio Actual Value: Lists the ratio of the frequency to the clock speed

5.3.2 IDE Configuration

Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration

of the IDE devices installed in the system.
