ECW-281B/281B2-R30/N270 Embedded System
Page 95
LVDS1 Panel Type [by H/W]
Use the LVDS Panel Type to determine the LCD panel resolution. Configuration options
are listed below:
640x480 18b
800x480 18b
800x600 18b
1024x768 18b
1280x1024 36b
1400x1050 36b
1440x900 36b
1600x1200 36b
1280x720 18b
by H/W D
EFAULT
5.7.2 South Bridge Chipset Configuration
The South Bridge Chipset Configuration menu (BIOS Menu 20) allows the southbridge
chipset to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
South Bridge Chipset Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Audio Controller
[Enabled]
Options
Enabled
Disabled
Select Screen
↑ ↓ Select
Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 20: South Bridge Chipset Configuration
Audio Controller [Enabled]
The Audio Controller option enables or disables the audio controller.
