IMB-H612 Mic ro -ATX Mo th e rb o a rd
P a g e 74
 L2 Cache: Lists the amount of storage space on the L2 cache.
 L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.4 S ATA Co n fig u ra tio n
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode
[IDE Mode]
Serial-ATA Controller 0 [Compatible]
Serial-ATA Controller 1 [Enhanced]
SATA Port0 Not Present
SATA Port1
Not Present
SATA Port2
Not Present
SATA Port3
Not Present
(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
 S ATA Mo d e [IDE Mo d e ]
Use the SATA Mode option to configure SATA devices as normal IDE devices.

Disable Disables SATA devices.

IDE Mode D EFAULT Configures SATA devices as normal IDE device.

ACHI Mode Configures SATA devices as AHCI device.

RAID Mode Configures SATA devices as RAID device.
 Serial-ATA Co n tro ller 0 [Co m patib le ]
Use the Serial-ATA Controller 0 option to configure the Serial-ATA controller mode when
the SATA mode is set to IDE Mode.
