IMB-H612 Mic ro -ATX Mo th e rb o a rd
P a g e 85
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+50 C
SYS Temperature :+44 C
CPU FAN Speed :2189 RPM
SYS FAN Speed :N/A
VCC3V :+3.344 V
V_core :+1.248 V
+1.05V :+1.064 V
VDDR :+1.616 V
VSB3V :+3.424 V
VBAT :+2.816 V
5VSB :+4.968 V
> FAN 1 Configuration
> FAN 2 Configuration
Smart FAN Configuration
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: H/W Monitor
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speeds:
o CPU Fan Speed
o System Fan Speed
 Voltages:
o VCC3V
o Vcore
o +1.05V
o VDDR
o VSB3V
o VBAT
o 5VSB
