IMB-H612 Mic ro -ATX Mo th e rb o a rd
P a g e 16
3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
ATX power connector 24-pin ATX ATX
Battery connector Battery holder BAT1
CPU fan connector 4-pin wafer CPU_FAN
CPU power connector 4-pin Molex CPU12V1
DDR3 DIMM slots DDR3 DIMM slot CHA_DIMM1,
CHB_DIMM1
Digital I/O connector 10-pin header DIO1
Front panel audio connector 10-pin header FP_AUDIO
Front panel connector 14-pin header F_PANEL
I2C connector 4-pin wafer I2C_1
PCI slots PCI slot PCI1, PCI2
PCIe x1 slots PCIe x1 slot PCIEX1_SLOT1,
PCIEX1_SLOT2,
SATA 3Gb/s drive connectors 14-pin SATA
connector
SATA12, SATA34
Serial port connector, RS-422/485 4-pin wafer COM6
Serial port connectors, RS-232 10-pin box header, COM3, COM4,
COM5
Serial port connectors, RS-232 40-pin box header COM7-10
SMBus connector 4-pin wafer SMBUS_1
SPI connector 6-pin wafer SPI1
System fan connectors 3-pin wafer SYS_FAN1,
SYS_FAN2
TPM connector 20-pin header TPM
