IMB-H612 Mic ro -ATX Mo th e rb o a rd
P a g e 8
Specification/Model IMB-H612
Display Port VGA1 integrated in Intel® H61
VGA2 integrated in Chrontel CH7317B
Ethernet Two RJ-45 ports
Keyboard/Mouse One external PS/2 keyboard/mouse port
TPM One 20-pin header
Front Audio One 10-pin header
SMBus One 4-pin wafer
I2C One 4-pin wafer
CPU One 4-pin CPU fan connector
Two 3-pin system fan connectors
Serial Ports Two external RS-232 via DB-9 male connectors
Three RS-232 via internal 10-pin headers
Four RS-232 via internal 40-pin box headers for IMB-H612B
One RS-422/485 via internal 4-pin header
USB ports Four external USB 2.0 ports by rear IO
Six internal USB 2.0 ports via three 8-pin headers
Serial ATA Four SATA 3Gb/s connectors
Environmental and Power Specifications
Power Supply AT / ATX power supply supported
Power Consumption [email protected], [email protected], [email protected], [email protected] A (Intel® 3.10GHz
Core™ I5-2400 with two 1333 MHz 4GB DDR3 DIMMs)
Operating Temperature -10ºC ~ 60ºC
Operating Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 244 mm x 244 mm
Weight GW/NW 1200 g / 680 g
Table 1-2: IMB-H612 Specifications
