Wi-Fi Settings (Optional)
9650-0902-01 Rev. K 55
Gateway IP Address
This setting allows you to specify the router’s IP used in the static configuration.
Note: This setting is accessible only when DHCP/Static IP is set to Static IP.
Values are as follows:
Procedure
Follow these steps to set up a Gateway IP Address.
Possible Values: XXX.XXX.XXX.XXX where XXX is 000 to 255
Default: 192.168.100.001
Step Action
1. From the Select Configuration Categories screen,
select Wi-Fi, then press the Enter softkey.
The Wi-Fi Configuration screen appears.
2. Press the Next Item softkey until Gateway IP
Address appears and press the Change Value
softkey.
The Set Gateway IP Address screen appears.
3. Use the softkey as follows:
•

— moves the highlight left and right
through the character selection table.
• Enter Char — enters the highlighted
character for each digit of the IP address.
• Return — returns you to the Wi-Fi
Configuration screen. Press the Return
softkey when you are finished entering the
address.
Next
Item
Prev
Item
System Configuration
Wi-Fi Configuration
Defib History
Transfer Mode
DHCP/
Static IP
Both
Static IP
Main
Menu
Exit
Config
Category
List
Change
Value
Full Disclosure
Transfer Mode
Server
Page 1 of 7
System Configuration
Set Gateway IP Address
192.168.100.001
.
Return
Enter
Char
1
Cancel 4
7
2
5
8 3
6
9
0
<
<
.
