Ecg settings, Notch filter, Display lead on power-up – ZOLL R Series Monitor Defibrillator Rev K CONFIGURATION User Manual
Page 25: Frequency response
ECG Settings
9650-0902-01 Rev. K
19
ECG Settings
ECG monitoring settings are attributes associated with using the R Series unit for ECG
monitoring, and include:
•
Notch Filter
•
Display Lead on Power-Up
•
Frequency Response
•
Gain on Power Up
•
Enable Leads Off
•
Enable Pacer Detection
Notch Filter
This setting allows you to select the ECG Notch Filter frequency for proper ac mains
interference rejection.
Values are as follows:
Display Lead on Power-Up
This setting allows you to select the lead to be displayed when you power on the unit.
Values are as follows:
Frequency Response
This setting allows you to select the ECG filter bandwidth to be used during ECG monitoring.
You can set the unit’s frequency to either help reduce noise, help with the diagnostic response,
or set it as a default response.
Values are as follows:
Possible Values:
50 Hz, 60 Hz
Default:
60 Hz
Possible Values:
Paddles/Pads, Lead I, Lead II, Lead III
Default:
Paddles/Pads
Possible Values:
0.5 - 21 Hz, 0.5 - 40 Hz, 1.0 - 21 Hz
Default:
0.5 - 21 Hz
