14
BTTracer Protocol Analyzer User’s Manual CATC SW Version 2.20
2.6 Recording Bluetooth 1.2 and 1.1 Traffic
By default, BTTracer is configured to record in a mode compliant with the
Bluetooth 1.1 specification. This mode is required if you are using
BTTrainer to generate traffic (BTTrainer is compliant only with the
Bluetooth 1.1 specification).
To record traffic in a mode compliant with the Bluetooth 1.2 specification,
perform the following steps.
Step 1
From the menu, select Setup > System Configuration ...
A dialog box opens.
Step 2
Select BT1.2 (BTTracer only).
The following message appears.
Step 3
Click OK.
Step 4
Shutdown the BTTracer application by clicking the X in the
top right corner of the application.
Step 5
Restart the BTTracer application from the Start menu:
Start>Programs >CATC>BTTracer Suite>BTTracer.
The application starts in the Bluetooth 1.2 mode.
Determining Which Bluetooth Mode You are In
You can quickly determine whether BTTracer is operating in the 1.1 or 1.2
modes from the Setup command described above.
Step 1 From the menu, select Setup > System Configuration ...
