11

BTTracer Protocol Analyzer User’s Manual

CATC

SW Version 2.20

Wide Range AC Connector Module

The power module is composed of:

Power on/off switch

Power socket

Enclosed 5x20 mm 2.0A 250 V fast acting glass fuse

Warning For continued protection against fire, replace fuse only with the type

and rating specified above.

2.4 Setting Up the Analyzer

A UPAS can support up to two BTTracer probes. These modules will come
factory-installed in the UPAS. In a single probe system, BTTracer will
come installed in the left slot.

To set up a one or two probe system,

Step 1

Attach the Antenna to the ANT connection point for each
analyzer probe. The antenna should point up.

Step 2

Connect the provided AC power cord to the rear of the UPAS and
to a 100-volt to 240-volt, 50 Hz to 60 Hz, 100 W power outlet.

Note

The Analyzer is capable of supporting supply voltages between 100-volt and
240-volt, 50 Hz or 60 Hz,

thus supporting all known supply voltages around the

world.

Step 3

Turn on the power switch on the rear of the analyzer.

Note

At power-on, the analyzer initializes itself in approximately ten seconds and
performs an exhaustive self-diagnostic that lasts about five seconds. The Trigger
LED illuminates during the power-on testing and turns off when testing is
finished. If the diagnostics fail, the trigger LED blinks continuously, indicating a
hardware failure. If this occurs, call CATC Customer Support for assistance.

Step 4

Connect the USB cable between the USB port on the back of the
analyzer and a USB port on the analyzing PC.

The host operating system detects the analyzer and begins to install the USB
driver.

2.5 Installing the Analyzer Software on the PC
