Automation Command and Query Reference Manual - Control Reference
Sets/Queries the state of tracking of a pair of cursors. If tracking is enabled then when the first cursor
is moved, the second will track at a constant distance from it.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set cursors tracking on.
app.Cursors.Track = True
Example
XPos1 Double
From -1.79769e+308 to 1.79769e+308 step 0 Range
Sets/Queries the horizontal position of the first cursor, in the units of the horizontal variable.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the horizontal position of the first cursor to 50 ns.
app.Cursors.XPos1 = 50e-9
Example
XPos2 Double
From -1.79769e+308 to 1.79769e+308 step 0 Range
Sets/Queries the horizontal position of the second cursor, in the units of the horizontal variable.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the horizontal position of the second cursor to 4.5 ms.
app.Cursors.XPos2 = 4.5e-3
Example
YPos1 Double
From -3.99 to 3.99 step 0.01 Range
Sets/Queries the vertical position of the first cursor, in graticule divisions.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the vertical position of the first cursor.
app.Cursors.YPos1 = 3.4
Example
1-68
918499 RevA
