Automation Command and Query Reference Manual - Control Reference

HorOffsetOrigin

Double

From 0 to 10 step 1

Range

Sets/Queries the origin, in graticule divisions, of the time scale in which HorOffset is measured.
The value 0 corresponds to the left edge of the graticule. The value 10 corresponds to the right edge
of the graticule. Requesting a value outside the range will select the nearest allowed value.

Description

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Set the origin of the horizontal trigger offset to 4.0 divisions.
app.Acquisition.Horizontal.HorOffsetOrigin = 4.0

Example

HorScale

DoubleLockstep

From 2e-010 to 1000 step 2e-009, locked to 1 2 5, fine grain allowed=false, on=false

Range

Sets/Queries the horizontal scale in time per division.

Description

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Set the horizontal acquisition scale to 200 ns/div.
app.Acquisition.Horizontal.HorScale = 2.0e-7

Example

HorUnits

String

Any number of characters

Range

Queries the units in which the horizontal scale is measured.

Description

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Obtain the units of the horizontal scale.
HorizUnit = app.Acquisition.Horizontal.HorUnits

Example

MaxSamples

DoubleLockstep

From 500 to 1e+007 step 25000, locked to 1 2.5 5, fine grain allowed=false, on=false

Range

Sets/Queries the maximum permissible number of samples to be used in the acquisition memories.
At the faster sample rates, the actual number used may be less than this maximum.

Description

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Set the available memory length per channel to 500
app.Acquisition.Horizontal.MaxSamples = 500

Example

1-22

918499 RevA
