InputY Enum
Sets/Queries the name of the input channel for the Y axis of the X-Y plot.
Description
Values
C1
C2
C3
C4
Digital1
Digital2
Digital3
Digital4
ET
F1
M1
M2
M3
M4
Z1
Z2
Z3
Z4
Persisted Bool
Sets/Queries the persisted state of the X-Y plot. If the Display.LockPersistence control is set to
'AllLocked' then the persisted state of all displayed waveforms will be the same. If the
Display.LockPersistence control is set to 'PerTrace' then the persisted state of each waveform may be
independently controlled.
Description
PersistenceSaturation Integer
From 0 to 100 step 1 Range
Sets/Queries the saturation threshold for persisted X-Y plot. All information at this level or above will
be recorded with the same color or intensity. See the general description above for a discussion of
the locked and unlocked persistence modes.
Description
