Automation Command and Query Reference Manual - Processor Reference

Window

Enum

Sets/Queries the type of window for the FFT function trace Fx.

Description

Values

BlackmanHarris

FlatTop

Hamming

Rectangular

VonHann

FLOOR

app.Math.Fx.OperatorYSetup (Operator = "Floor")

Most negative or minimum values for an ensemble of sweeps, or "Floor"

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Configure F1 to measure the Floor of the first 1000
' sweeps of C1
app.Math.F1.View = True
app.Math.F1.Source1 = "C1"
app.Math.F1.MathMode = "OneOperator"
app.Math.F1.Operator1

Example

ClearSweeps

Action

Initiates a clear sweeps action for the Floor function trace Fx.

Description

LimitNumSweeps

Bool

Sweeps

Integer

From 1 to 1000000 step 1

Range

Sets/Queries the maximum number of sweeps for the Floor function trace Fx.

Description

ClearSweeps

Action

LimitNumSweeps

Bool

Sweeps

Integer

INTEGRAL

app.Math.Fx.OperatorYSetup (Operator = "Integral")

Integral of the linearly rescaled (multiplier and adder) input.

Adder

Double

AutoFindScale

Bool

2-5

918499 RevA
