Automation Command and Query Reference Manual - Control Reference
PersistenceTime Enum
Sets/Queries the state of the Persistence Time control. Controls the persistence decay time for the Xy
persistence. See the general description above for a discussion of the locked and unlocked
persistence modes.
Description
Values
0.5s
10s
1s
20s
2s
5s
Infinite
ShowLastTrace Bool
Sets/Queries the state of the Show Last Trace control. If True then when this trace is displayed in
persistence mode the last acquired waveform will be superimposed on the accumulating persistence
map.
See the general description above for a discussion of the locked and unlocked persistence modes.
Description
RESULT app.Math.XY.Out.Result
Properties of the type xxxx.Out.Result.yyyy are those of the last completed acquisition. They are not affected if other
cvars are changed after that acquisition was completed. This distinction between "Out.Result" properties and other
cvars is most important when the trigger mode is Single or Stopped. You should treat "Out.Result" properties as read-
only.
Note that this XY result object is very similar, but not identical to the result object exposed by the channel and math
traces. The differences are due to the fact that the XY trace returns pairs of data values, one for X, one for Y.
For a detailed description of all properties available for the output of an XY trace, please see Chapter 1.
MEASURE app.Measure
Variables of the form app.Measure control the parameters P1 through P8, and their associated statistical results and
histicons.
Names of the forms app.Measure.Measure("Premote").xxxx and app.Measure.Measure("Px").xxxx are aliases of
simpler names which are described in this section of the manual. Examples of alias pairs are as follows -
app.Measure.Measure("Premote").OutResult is equivalent to app.Measure."Premote".OutResult
app.Measure.Measure("Px").Statistics is equivalent to app.Measure.Px.Statistics
Please see under Acquisition.Channels for a programming example.
ClearAll Action
ClearSweeps Action
SetGateToDefault Action
ShowMeasure Bool
