Automation Command and Query Reference Manual - Control Reference

VariableVerZoom

Bool

Sets/Queries the ability to zoom vertically by a continuously variable factor. Note that if a vertical
zoom of 0.9 is set, while variable zoom is off, the vertical zoom will be set to 1.0. If the variable zoom
is then enabled, the factor of 0.9 will have been remembered, and it will be used. Note that the
previous value will not be remembered during a power-cycle.

Description

VerPos

Double

From -1.5 to 1.5 step (8 digits)

Range

Sets/Queries the vertical position of center of the grid on the zoomed trace Fx. The unit of
measurement is the screen height, that is, 0.375 means a shift of three of the eight divisions. A
positive value moves the trace downwards.

Description

VerZoom

Double

From 0.1 to 100 step (8 digits)

Range

Sets/Queries the vertical magnification of the trace Fx. The magnification will be in a 1 2 5 10
sequence unless VariableVerZoom has been set to True, in which case it will be continuously variable.

Description

XY

app.Math.XY

This set of variables controls the display of data in X vs. Y mode. Only Valid when the instrument is in XY, XYSingle,
or XYDual display modes.

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Switch to XY+Dual Grid Mode
app.Display.GridMode = "XYDual"

' Configure XY to show C1 vs. C2 in 3D Persistence mode
app.Math.XY.InputX = "C1"
app.Math.XY.InputY = "C2"
app.Math

Example

ClearSweeps

Action

Clears persistence X-Y plot.

Description

ClearSweeps

Action

InputX

Enum

InputY

Enum

Persisted

Bool

PersistenceSaturation

Integer

PersistenceTime

Enum

ShowLastTrace

Bool
