Automation Command and Query Reference Manual - Control Reference

UseGrid

String

Any number of characters

Range

Sets/Queries the grid in use for the zoom trace Zx.
See also app.Acquisition.Cx.UseGrid.

Description

View

Bool

Sets/Queries the trace's 'Viewed' state. When true, the trace is displayed on one of the display
graticules. Note that even when a trace is not visible, it may be used as a source for Math, Measure,
etc.

Description

ViewLabels

Bool

Sets/Queries whether the user-defined labels for the trace are visible.
See Also: LabelsPosition and LabelsText controls.

Description

RESULT

app.Zoom.Zx.Out.Result

ZOOM

app.Zoom.Zx.Zoom

HorPos

Double

From -0.5 to 0.5 step (8 digits)

Range

Horizontal Position of the trace, normalized to a value between -0.5 and 0.5. A value of zero is the
default, and indicates no position change relative to the source trace.

Description

HorZoom

Double

From 0.1 to 1e+006 step (8 digits)

Range

Horizontal Zoom setting. Locked to a 1, 2, 5 sequence unless VariableHorZoom is set to True .

Description

HorPos

Double

HorZoom

Double

ResetZoom

Action

VariableHorZoom

Bool

VariableVerZoom

Bool

VerPos

Double

VerZoom

Double

1-200
