Automation Command and Query Reference Manual - Control Reference
SaveTo Enum
Sets/Queries type of destination for waveform save.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the destination to Memory for waveform save.
app.SaveRecall.Waveform.SaveTo = "Memory"
Example
Values
File Save into file on a mass-storage device
Memory Save into an internal memory (M1..M4)
TraceTitle String
Any number of characters Range
Sets/Queries the title (prefix) to use when naming saved traces. This prefix will have the family
(sequence) number appended to it when forming the filename.
Description
WaveFormat Enum
Sets/Queries the format to use when saving waveform data into a file. 'Binary' is the most efficient,
storing one or two bytes per data sample, depending upon the number of significant bits. When in
ASCII mode, the Subformat and Delimiter controls define the data format.
Description
Values
ASCII Plain ASCII files with choice of various delimiters
Binary LeCroy's standard binary waveform format
Excel
MathCad
MATLAB
WaveformDir FileName
Any number of characters Range
Sets/Queries the directory for storing waveform files.
Description
SERIALDECODE app.SerialDecode
AnnotationPositionPreference Enum
LinkedToTrigger1 Bool
LinkedToTrigger2 Bool
LinkedToTrigger3 Bool
LinkedToTrigger4 Bool
SelectDecoder Enum
1-148
918499 RevA
