Automation Command and Query Reference Manual - Processor Reference

VerScale

DoubleLockstep

From 1e-012 to 1e+013 step 10000, locked to 1 2 5, fine grain allowed=false, on=false

Range

Sets/Queries the vertical scale of the derivative function Fx.

Description

ENHANCEDRESOLUTION

app.Math.Fx.OperatorYSetup (Operator = "EnhancedResolution")

Bits

Enum

Number of bits of enhanced resolution. ERES is a FIR filter with a gaussian frequency response.

Description

Values

0.5

Enhance by 0.5 bits

1

Enhance by 1 bits

1.5

Enhance by 1.5 bits

2

Enhance by 2 bits

2.5

Enhance by 2.5 bits

3

Enhance by 3 bits

Bits

Enum

ENVELOPE

app.Math.Fx.OperatorYSetup (Operator = "Envelope")

Envelope of minimum and maximum values for an ensemble of sweeps, or 'Extrema'

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Configure F3 to be an envelope of C1
app.Math.F3.View = True
app.Math.F3.Source1 = "C1"
app.Math.F3.MathMode = "OneOperator"
app.Math.F3.Operator1 = "Envelope"
app.Math.F3.Operat

Example

ClearSweeps

Action

Initiates a Clear Sweeps operation for envelope function trace Fx.

Description

ClearSweeps

Action

LimitNumSweeps

Bool

Sweeps

Integer

2-3
