Automation Command and Query Reference Manual - Control Reference
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' get into the custom parameter mode
app.Measure.MeasureMode = "MyMeasure"
app.Measure.ClearAll
app.Measure.StatsOn = True
app.Measure.HistoOn = False
' Configure P1 to measure a
Example
ClearAll Action
Resets all parameter setups, turning each of the parameters view to "off", the MeasurementType to
"measure"and the selected paramEngine to "Null".
Description
ClearSweeps Action
Clears the accumulated statistics for parametersP1 to P8 as well as the acumulated statistics for their
associated histicons.
Description
SetGateToDefault Action
Sets the measure gate to its default state. Valid only when in either Std. Vertical or Std. Horizontal
measurement modes. For MyMeasure see the equivalent controls under Px.
Description
ShowMeasure Bool
Defines whether the measure results table is displayed or not.
Description
StatsOn Bool
Sets/Queries the visibility of parameter statistics. Note: the statistics are accumulated whether the
view of them is on or not, so you needn't have StatsOn = "On" to collect statistics.
Description
StdGateStart Double
From 0 to 10 step 0.01 Range
Sets/Queries the position of the left hand limit of the measure gate (n divisions).
Valid only when in either Std. Vertical or Std. Horizontal measurement modes. For MyMeasure see the
equivalent controls under Px.
Description
StatsOn Bool
StdGateStart Double
StdGateStop Double
1-120
918499 RevA
