69
7. Specifi
cations
IX-NNC80 (Arm Length 800, Clean-room Specification)
Item Specifications
Type IX-NNC80 - L-T1
Cleanliness class (*10) Class 10 (0.1 Pm)
Degree of freedom Four degrees of freedom
Overall arm length 800
Arm 1 length 450
Arm 2 length
mm
350
Axis 1 (arm 1) AC servo motor + Speed reducer
Axis 2 (arm 2) AC servo motor + Speed reducer
Axis 3 (vertical axis) AC servo motor with brake + Belt + Ball-screw spline
Drive method
Axis 4 (rotational axis) AC servo motor with brake + Speed reducer + Belt + Spline
Axis 1 (arm 1) 750
Axis 2 (arm 2) 400
Axis 3 (vertical axis) 400
Motor capacity
Axis 4 (rotational axis)
W
200
Axis 1 (arm 1) r125
Axis 2 (arm 2)
degree
r145
Axis 3 (vertical axis) (*1) mm 200 (Optional: 400)
Movement range
Axis 4 (rotational axis) degree r360
Axis 1 + Axis 2 (maximum composite speed) 7121
Axis 3 (vertical axis)
mm/sec
1583
Maximum
operating speed
(*2)
Axis 4 (rotational axis) degree/sec 1200
Axis 1 + Axis 2 r0.015
Axis 3 (vertical axis)
mm
r0.010
Positioning
repeatability (*3)
Axis 4 (rotational axis) degree r0.005
Cycle time (*4)
0.52
Rated 5
Load capacity
Maximum
kg
20
Dynamic (*8) 265 (27.0)
Push-in thrust of
axis 3 (vertical axis)
Static (*9)
N (kgf)
188 (19.1)
Permissible moment of inertia (*5) kg ˜m 2 0.1
Permissible load
on axis 4
Permissible torque N ˜m (kgf˜cm) 6.7 (68.3)
Permissible tool diameter (*6) mm I100
Origin detection Absolute
User wiring D-sub 25-pin connector with 25-core AWG26 shielded cable (socket)
Alarm indicator (*7) One small, red LED indicator (rated voltage: 24 V)
User piping
Two air tubes (outer diameter: I6, inner diameter: I4) (normal service pressure: 0.8 MPa)
Two air tubes (outer diameter: I4, inner diameter: I2.5) (normal service pressure: 0.8 MPa)
