46
6. Inspection/Maintenance
(5) Affix the cover (base) using the countersunk head screws [1] (six pieces) (tightening torque: 0.74
N ˜m).
[1] 6 - M3 x 8
Do not tighten the screws to the specified torque in one go. First
tighten the screws to the position shown to the left, and while
pushing the cover in the direction of the arrow tighten the screws
on both sides evenly to ensure tight sealing.
z When installing the cover (base), be careful not to pinch the cables inside.
z Disassembly of the cover generates dust. Before disassembling the cover, move the robot to a
location where dust will not cause problem, or cover the robot with a plastic sheet, etc., to prevent
dust from scattering.
Caution
