10. Connecting with the Controller
38
10. Connecting with the Controller
Connect the connector at the end of the cable, to the controller.
For the connection methods of the IO cable, controller power cable, PC connection cable, etc., refer to the
instruction manuals for your controller and PC software.
This is a connection example with the XSEL P/Q controller. This actuator can also be connected with the
SSEL or SCON controller.
PC software
(IA-101-X-MW)
XSEL P/Q controller
Host system (PLC)
Control power supply,
drive power supply
Encod
e
r
c
abl
e
Motor
cable
Teaching
pendant
Linear servo actuator
