6SHFL¿FDWLRQV
23
6.3 N19SS, N19SM
Model Unit 066 060
Stroke mm
144 to 2592
(in 144 steps)
72 to 2232
(in 144 steps)
Rated thrust N 100
Maximum thrust N 300
Maximum speed mm/sec 2,500 (*1)
Maximum acceleration/deceleration G 3 (*2)
Maximum loading capacity kgf 30 (*3)
Positioning repeatability rmm 0.005
Running life: 10,000 km
Ma: 61.94 (6.32) Load moment
N. m
(kgf
ycm)
Mb: 61.94 (6.32)
Mc: 61.94 (6.32)
Overhang load length mm Ma direction: 700 max.
Mb/Mc directions: 700 max.
(*1) The maximum speed may not be reached depending on the stroke.
(*2) The specific value varies depending on the operating conditions.
