178 Agilent N518xA, E8663B, E44x8C, and E82x7D Signal Generators Programming Guide
Programming the Status Register System
Status Groups
Data Questionable Calibration Condition Register
The Data Questionable Calibration Condition Register continuously monitors the calibration status of
the signal generator. Condition registers are read only.
Data Questionable Calibration Transition Filters (negative and positive)
The Data Questionable Calibration Transition Filters specify which type of bit state changes in the
condition register set corresponding bits in the event register. Changes can be positive (0 to 1) or
negative (1 to 0).
Data Questionable Calibration Event Register
The Data Questionable Calibration Event Register latches transition events from the condition register
as specified by the transition filters. Event registers are destructive read- only. Reading data from an
event register clears the content of that register.
Table 4-11 Data Questionable Calibration Condition Register Bits
Bit Description
0 a
a.In the N5181A, E4428C, E8257D, and the E8663B, this bit is set to 0.
I/Q Calibration Failure. A 1 in this bit position indicates that the I/Q modulation calibration experienced a failure.
1 b
b.In the N5181A and N5182A, this bit is set to 0.
DCFM/DC ΦM Zero Failure. A 1 in this bit position indicates that the DCFM/DCΦM zero calibration routine has
failed. This is a critical error. The output of the source has no validity until the condition of this bit is 0.
2 −14 Unused. These bits are always set to 0.
15 Always 0.
Query: STATus:QUEStionable:CALibration:CONDition?
Response: The decimal sum of the bits set to 1.
Commands: STATus:QUEStionable:CALibration:NTRansition (negative transition), or
STATus:QUEStionable:CALibration:PTRansition (positive transition), where is
the sum of the decimal values of the bits you want to enable.
Queries:
STATus:QUEStionable:CALibration:NTRansition?
STATus:QUEStionable:CALibration:PTRansition?
Query: STATus:QUEStionable:CALibration[:EVENt]?
