Figure 4- 3 – Agilent Technologies N5183A MXG User Manual

Page 152

background image

142

Agilent N518xA, E8663B, E44x8C, and E82x7D Signal Generators Programming Guide

Programming the Status Register System
Overview

Figure 4-3

E8663B: Overall Status Byte Register System (1 of 2)
