174
Parts and Materials
Pump Head Assembly with Seal Wash Option
Pump Head Assembly with Seal Wash
Option
Table 21 Pump Head Assembly with Seal Wash Option
Item Description Part Number
Complete assembly, including parts marked with * G1311-60005
1* Sapphire plunger 5063-6586
2* Plunger housing (including spring) G1311-60002
3* Support ring, seal wash 5062-2465
4* Secondary seal 0905-1175
5* Wash tube (1.0 m) 0890-1764
6* Gasket, seal wash (pack of 6) 5062-2484
7* Seal keeper 5001-3743
8* Seal (pack of 2) or
Seal (pack of 2), for normal phase applications 5063-6589
0905-1420
9* Pump chamber housing G1311-25200
10 Active inlet valve G1312-60010
Replacement cartridge for active inlet valve 5062-8562
11 Outlet ball valve (complete with cartridge) G1311-60012
12* Screw lock 5042-1303
13 Purge valve G1311-60009
14* Screw M5, 60 mm lg 0515-2118
Seal wash upgrade kit (see page 180 ) 01018-68722
