Liquid Controls SP3000 User Manual
Page 5
5
1.3
APPLICATION
1 2 3 4 5 6
P
*
Alarm Outputs
Pulse Output
RS232 Output
4-20mA Output
PRESSURE
TRANSDUCER
SP714 PULSE
AMPLIFIER
100 OHMS RTD
FLOWMETER
SP3000
MASS FLOW
COMPUTER
BELL
LIGHT
REMOTE
TOTALIZER
PRINTER
*
Pressure Transducer sends 4-20mA signal to Model SP3000
*
100 ohms RTD direct hook-up to Model SP3000
*
Meter Mounted SP714 Pulse Amplifier sends digital signal to Model SP3000
*
Model SP3000 calculates flow and sends out signals
*
5V pulse out to remote totalizer in supervisory area
*
4-20mA out to stripchart recorder tracks trends
*
RS-232 out to printer for data logging
*
Alarm relays activate bell and/or light as needed
