22
3.3 SELECTING THE ENGINEERING UNITS
Engineering units establish the measuring system that is used for entry and display of the operating
parameters.
Four options are available to select the desired units for the application:
English (Imperial): Temperature
o
F; Pressure PSI
kPa (Metric): Temperature
o
C; Pressure kPa
Kg/cm
2
(Metric) Temperature
o
C; Pressure kg/cm
2
bar (metric) Temperature
o
C; Pressure bar
NOTE: The output data display units and the required variable units are determined by the
Computation and Engineering Units selected. A complete listing of input and output data units is given
in Appendix i.
To enter the Engineering Units Menu:
Display Shows:
Press:
Sponsler V6.13 MS197
Engineering Units?
Engineering Units?
To advance menu
English?
To backup menu
To select displayed option
Engineering Units Menu:
Engineering Units:
English?
Engineering Units:
kPa (Metric)?
Engineering Units:
kg/cm
2
(Metric)?
Engineering Units:
bar (Metric)?
3.4 SETTING THE HARDWARE
The hardware selection determines the input terminals from which the unit will accept raw data. Internal
analog switches activate the proper terminals for the input type selected. Review the specification sheet for
each input device being used with the system to determine the required selection.
To access the Hardware Menu:
Display Shows: Press:
Sponsler V6.13 MS197
Set Hardware?
ENT
ENT
A
B
ENT
