A-2
Analog Input: 0 - 10 VDC Range
33 K
Ω
Input Impedance
12 Bit Resolution
±
0.1% Linearity Error - Typical
±
0.05% Drift Error - Typical - Isolated Mode
±
0.2% Drift Error - Typical - Non-Isolated Mode
Digital Outputs: Open-Collector Driver (ULN2003)
(50 VDC max, 200 mA continuous, 500 mA peak)
Optically Isolated
Dig_Out1
Dig_Out2
Drive Output: Phase Fired - Single Quadrant
0 - 90 VDC, 10.0 FLA, 1/4 to 1 HP (115V version)
0 - 180 VDC, 10.0 FLA, 1/2 to 2 HP (230V version)
PM Motors
Current Limit: 4.0 to 10.0 Amps RMS
4.0 to 15.0 Amps Peak
Aux Supply: +5VDC + 5%
150 mA, Max
non-isolated
Serial Interface: RS485
300 to 9600 Baud
Full parameter access and control
Power Requirements: 115 +15% VAC (model # 3200-1938)
230 +15% VAC (model # 3200-1939)
50/60 Hz
0.1 Amp + motor current
Line Loss: 10 mSec ride through
Operating Temperature: 0
°
to 55
°
C Int. Enclosure
0
°
to 40
°
C Ext. Ambient temperature when
installed in an enclosure no smaller than 12" X 10" X 8"
Storage Temperature: -25
°
to 70
°
C
Humidity: 0 to 95% non-condensing
Physical Dimensions: 4.0 inches height
4.0 inches width
6.0 inches depth (Interior Panel)
