Total Access 1240 Installation and Maintenance Practice
5-40 61179605L5-5B
Static IP Settings - for IP over Ethernet Menu
The Static IP Settings - for IP over Ethernet menu (see
Figure 5-27 ) is used to manually
provision all of the IP settings.
Figure 5-27. Static IP Settings - for IP Over Ethernet Menu
NOTE
The Media Access Control (MAC) address, which is set at the
factory, is required to configure the DHCP server.
The Static IP Settings - for IP over Ethernet menu options are shown in Table 5-31 .
3 Configure IP Depending on the setting of the Mode option, the
Configure IP option displays one of the following menus:
• “Static IP Settings - for IP over Ethernet Menu” on
page 5-40
• “Dynamic IP Settings - for IP over Ethernet Menu”
on page 5-43
Table 5-30. Mode Selection and Current IP Settings Menu Options (Continued)
Option Description Function
Total Access 1240 - IPoE Fed
Unacknowledged Alarms: None
Static IP Settings - for IP over Ethernet
1. IP address 192.168.1.1
2. Subnet mask 255.255.255.0
3. Default Gateway 192.168.1.254
4. TFTP IP address 10.200.200.218
5. Reset IP Factory Defaults
6. IP VLAN ID 1
(Vlan = 1 is untagged / 2-4094 is tagged)
MAC Address 00-a0-c8-12-4c-7c
Selection :
'?' - System Help Screen
